Textile Conveyor Belt
Textile Conveyor Belt
Polyester conveyor belt also called EP conveyor belts, whose tension resistant body is canvas woven by polyester in warp and polyamide in weft.
The belts have characteristics of low elongation in wrap and good through ability in weft, good water proof, and good wet strength, no mould, suitable for medium, long-distance and heavy-load transportation of materials. Because of the high initial modulus of polyester, the belts can choose a relative low safety factor. We provide various types of polyester conveyor belt with excellent quality and competitive price.
Specification and technical index of EP conveyor belt
|
Fabric type |
Fabric structure |
Fabric type |
Fabric thickness |
Strength series |
Cover rubber thickness |
Width |
Length |
||||||
|
warp |
weft |
2ply |
3ply |
4ply |
5ply |
6ply |
Upper |
Lower |
|||||
|
Polyester(EP) |
Polyester(E) |
Polyamide(P) |
EP-80 |
0.60 |
160 |
240 |
320 |
400 |
480 |
2.0-8 |
0-4.5 |
400-2200 |
<=300 |
|
EP-100 |
0.75 |
200 |
300 |
400 |
500 |
600 |
|||||||
|
EP-150 |
1.0 |
300 |
450 |
600 |
750 |
900 |
|||||||
|
EP-200 |
1.1 |
400 |
600 |
800 |
1000 |
1200 |
500-2200 |
||||||
|
EP-250 |
1.25 |
500 |
750 |
1000 |
1250 |
1500 |
|||||||
|
EP-300 |
1.35 |
600 |
900 |
1200 |
1500 |
1800 |
|||||||
|
EP-350 |
1.45 |
|
1050 |
1400 |
1750 |
2100 |
800-2200 |
||||||
|
EP-400 |
1.55 |
|
|
1600 |
2000 |
2400 |
1000-2200 |
||||||
|
EP-500 |
1.70 |
|
|
2000 |
2500 |
3000 |
|||||||
Other Textile reinforced material: CC/TC/NN/SW Etc.
