HYDRAULIC HOSE SAE 100 R3
INDAFLEX HYDRAULIC HOSE
SAE 100 R3
Double Fiber Braided Hydraulic Hose
Application:Transmission hydraulic fluids for medium pressure hydraulic systems of industry or agriculture.
Inner Tube: Black oil resistant synthetic rubber
Reinforcement: Two braid suitable fiber
Cover:Black, Oil ,Abrasion and weather resistant synthetic rubber
Working Temperature: -40℃ +100℃
Recommended For lower pressure hydraulic lines.Our fiber reinforcement hydraulic hose mainly used
in mine hydraulic support,oil exploration,suitable to engineer construction, crane transport,forging
metallurgy,mining equipment, hydraulic fluids for industry department mechanization and automatic
hydraulic systems,including petroleum base fluids.
Technical Details
|
Hose Size |
Hose I.D |
Hose O.D |
Working Pressure |
Min. Burst Pressure |
Min. Bend Radius |
Weight |
||||||
|
mm |
In. |
mm |
In. |
mm |
In. |
Bar |
Psi |
Bar |
Psi |
mm |
In. |
kg/m |
|
1/4 |
6.4 |
1/4 |
6.4 |
14.0 |
0.55 |
87 |
1260 |
348 |
5048 |
75 |
2.95 |
0.16 |
|
5/16 |
7.9 |
5/16 |
7.9 |
17.2 |
0.67 |
84 |
1218 |
336 |
4872 |
100 |
3.94 |
0.23 |
|
3/8 |
9.5 |
3/8 |
9.5 |
17.8 |
0.70 |
78 |
1130 |
312 |
5420 |
100 |
3.94 |
0.25 |
|
1/2 |
12.7 |
1/2 |
12.7 |
22.5 |
0.88 |
70 |
1015 |
280 |
4060 |
125 |
4.92 |
0.38 |
|
5/8 |
15.9 |
5/8 |
15.9 |
26.8 |
1.05 |
61 |
885 |
244 |
3540 |
140 |
5.51 |
0.45 |
|
3/4 |
19.1 |
3/4 |
19.1 |
30.6 |
1.20 |
52 |
754 |
208 |
3016 |
150 |
5.90 |
0.57 |
|
1 |
25.4 |
1 |
25.4 |
37.6 |
1.48 |
39 |
566 |
156 |
2260 |
205 |
8.10 |
0.75 |
|
1 1/4 |
31.8 |
1 1/4 |
31.8 |
44.5 |
1.75 |
26 |
377 |
104 |
1508 |
250 |
9.84 |
0.88 |
